PEANUT3 - BOX OF 200 / 150 / 1000 / 1250 (Std and LONG Variants)
PEANUT3 - BOX OF 200 / 150 / 1000 / 1250 (Std and LONG Variants)
Couldn't load pickup availability
The PEANUT 3 is available in two sizes. Each are single component, invisible connectors and provide the optimum solution for large scale manufacturers.
They are designed for fast assembly and compatible with end drilling machines, auto-insertion machines and large scale production line insertion machines.
The standard size PEANUT 3 component is designed for perfect 45° and face-to-face connections. Meanwhile, the PEANUT 3 Long provides an optimal solution for 90° and end-to-end connections.
Glue is recommended to be inserted within each 6mm hole and this allows all panels made with PEANUT components to be packed flat and depending on the tightness of the joint, can be reassembled
Key Benefits
- Self-clamping, invisible connector
- Packs flat when pre-inserted
- Creates an incredibly strong joint
- Quick and simple assembly
- Ability to reassemble many times
- Designed from glass fibre reinforced nylon
- 45° joints for 18mm+ material, 90° joints for 15.3mm+ material
- *Ideal for boring and insertion machines
Design
The PEANUT 3 is made of a strong reinforced plastic and has rows of teeth around the dowel end to provide gripping strength when inserted.
The PEANUT® head has been specially designed to maximise ease of assembly and joint strength. Due to its dome shape, the PEANUT® head smoothly slides along the slot created by the T-shaped PEANUT® Cutter.
In assembly, the PEANUT head rides over the lip of the PEANUT® slot and slides to the end, this action creates a strong clamping force, pulling the two panels together from the inside.
Tooling Requirements: PEANUT CUTTER
